Using Waves and VHDL for Effective Design and Testing : A Practical and Useful Tutorial and Application Guide for the Waveform and Vector Exchange Specification (Waves)

James P Hanna

ISBN 10: 0792397991 / ISBN 13: 9780792397991

Published by Springer Us Dez 1996, 1996

About this Item

Neuware - 2 Concept ( Tools - Specification ( Tools + Design Stages ( Tools - Implementation ( Tools Figure 1-1. A nominal, multi-stage development process From that beginning, we have progressed to the point where the EDA community at large, including both users and developers of the tools, are interested in more unified environments. Here, the notion is that the tools used at the various stages in the development process need to be able to complement each other, and to communicate with one another efficiently using effective file exchange capabilities. Furthermore, the idea of capturing all the tool support needed for an EDA development into a unified support environment is now becoming a reality. This reality is evidenced by some of the EDA suites we now see emerging, wherein several tool functions are integrated under a common graphical user interface (GUI), with supporting file exchange and libraries to enable all tool functions to operate effectively and synergistically. This concept, which we illustrate in Figure 1- 2, is the true future ofEDA.

Seller Inventory # 9780792397991

Bibliographic Details

• Title: Using Waves and VHDL for Effective Design and Testing : A Practical and Useful Tutorial and Application Guide for the Waveform and Vector Exchange Specification (Waves)
• Publisher: Springer Us Dez 1996
• Publication Date: 1996
• Language: English
• ISBN 10: 0792397991
• ISBN 13: 9780792397991
• Binding: Buch
• Condition: Neu

About this title

Synopsis

2 Concept ( Tools • Specification ( Tools + Design Stages ( Tools • Implementation ( Tools Figure 1-1. A nominal, multi-stage development process From that beginning, we have progressed to the point where the EDA community at large, including both users and developers of the tools, are interested in more unified environments. Here, the notion is that the tools used at the various stages in the development process need to be able to complement each other, and to communicate with one another efficiently using effective file exchange capabilities. Furthermore, the idea of capturing all the tool support needed for an EDA development into a unified support environment is now becoming a reality. This reality is evidenced by some of the EDA suites we now see emerging, wherein several tool functions are integrated under a common graphical user interface (GUI), with supporting file exchange and libraries to enable all tool functions to operate effectively and synergistically. This concept, which we illustrate in Figure 1- 2, is the true future ofEDA.

Synopsis

This text aims to serve different purposes. For the WAVES beginner, its tutorial will make the application of WAVES in typical, standard usage straightforward and convenient. For the more advanced user, the advanced topics will provide insight into the nuances of these useful capabilities. For all users, the tools, templates and examples given in the chapters, as well as on the companion disk, will provide a practical starting foundation for using WAVES and VHDL.
