Complete PCB Design Using OrCAD Capture and PCB Editor - Softcover


9780128176849: Complete PCB Design Using OrCAD Capture and PCB Editor

Synopsis

Complete PCB Design Using OrCAD Capture and PCB Editor, Second Edition, provides practical instruction on how to use the OrCAD design suite to design and manufacture printed circuit boards. Chapters cover how to Design a PCB using OrCAD Capture and OrCAD Layout, adding PSpice simulation capabilities to a design, how to develop custom schematic parts, how to create footprints and PSpice models, and how to perform documentation, simulation and board fabrication from the same schematic design. This book is suitable for both beginners and experienced designers, providing basic principles and the program's full capabilities for optimizing designs.

"synopsis" may belong to another edition of this title.

About the Authors

Kraig Mitzner is a consultant in Silverdale, WA, USA

Bob Doe joined OrCAD UK in April 1999 and moved to Cadence in January 2000 after Cadence acquired OrCAD. When Cadence appointed a UK Channel Partner in 2002, Bob moved to Parallel Systems Ltd. in September 2002 and has worked there since looking after post sales technical support and training courses. Parallel Systems provides front line support, sales and training for the OrCAD and Allegro Products. www.orcad.co.uk Parallel Systems has produced over 400 free tutorial videos for the Cadence software.

Alexander Akulin gained his engineering education in Moscow Aviation University in 1990. He worked for 9 years as an electronics engineer in a Nuclear Physics Institute of Moscow State University. In 1999 he has founded the EMS company in Moscow called PCB Technology, which became a big holding providing PCB design, manufacturing, and assembly services in Russia. Alexander as co-owner and CTO of this company participated in creation of the technical department of PCB supply chain, PCB design center and the assembly factory “from scratch”. In 2012 he founded, together with several partners, PCB SOFT which provided system integration and eCAD sales services. In 2015 PCB SOFT Ltd became Channel Partner of Cadence Design Systems, and started selling OrCAD, Allegro and Sigrity tools in Russia including providing support, education and workshop services.

Anton Suponin graduated in 2005 from Moscow State Technical University. He has considerable experience working at electronics manufacturing facilities, PCB manufacturing and PCB layout and simulation companies. He has accomplished a number of layouts of complex PCB designs with high-speed SERDES links, DDR memory, HDI stackups. While working in PCB design office, he learned Cadence Sigrity software and used it to simulate SI/PI in his PCB projects. Now he is a Cadence certified instructor on Allegro PCB Editor and Sigrity simulation tools

Dirk Müller has an electrical engineering degree from the University of Emden where he completed a thesis on computer architecture and data transmission for high-speed computers based on INMOS transputers. He has worked in customer support and custom adaptation of embedded computers to control industrial laser printers. He founded FlowCAD in 2003, a company selling and supporting PCB Design Software for customers in central Europe. Today he leads the development department and Design Services Group at FlowCAD

From the Back Cover

Complete PCB Design Using OrCAD Capture and PCB Editor, now fully updated to version 17.2, provides practical instruction on how to use the OrCAD design suite to design and manufacture printed circuit boards.

The book shows how to:

  • Design a PCB using OrCAD Capture and OrCAD Layout
  • Add PSpice simulation capabilities to a design, and how to develop custom schematic parts, footprints and PSpice models
  • Perform documentation, simulation and board fabrication from the same schematic design, ensuring continuity between the design and the manufactured product, saving time and money

Complete PCB Design Using OrCAD Capture and Layout is suitable for both the beginner, as it provides the basic principles of PCB design, and the experienced designer who wants to use the full capabilities of the software to optimize their designs.

"About this title" may belong to another edition of this title.

  • PublisherAcademic Press
  • Publication date2019
  • ISBN 10 0128176849
  • ISBN 13 9780128176849
  • BindingPaperback
  • LanguageEnglish
  • Edition number2
  • Number of pages612
